wxs双向限速器具体规格如下
refer to the following for the detailed specifications
序号 no. |
型号 |
绳轮节圆直径φ1(mm) |
绳轮直径φ(mm) |
钢丝绳直径 |
额定速度 |
绳张力(n) rope |
总高(h) |
|
1 |
wxs1 |
250 |
256 |
φ8 |
1.0 |
1000-3900 |
332 |
|
2 |
wxs2 |
300 |
306 |
φ8 |
1.50 |
1000-3900 |
357 |
|
3 |
wxs3 |
300 |
306 |
φ8 |
1.75 |
1000-3900 |
357 |
|
4 |
wxs4 |
250 |
256 |
φ8 |
0.5 |
1000-3900 |
332 |
|
5 |
wxs5 |
200 |
204 |
φ6 |
1.00 |
1000-2200 |
306 |
|
6 |
wxs6 |
300 |
306 |
φ8 |
1.60 |
1000-3900 |
357 |
|
7 |
wxs7 |
300 |
306 |
φ8 |
2.0 |
1000-3900 |
357 |
|
8 |
wxs8 |
300 |
306 |
φ8 |
2.5 |
1000-3900 |
357 |
|
9 |
wxs (y) |
200 |
204 |
φ6 |
0.40 |
1000-2200 |
306 |
|
绳轮节 |
钢丝绳 |
a |
绳中心至导轨中心距离(mm} |
中心至地面最小距离l2(mm) the minimum distance between the center and the ground |
|||||
|
适用导轨型号 the suitable guide rail type |
|||||||||
|
l1 |
l |
||||||||
|
t75 |
t89/t90 |
t114 |
t75 |
t89/t90 |
t114 |
||||
|
200 |
φ6 |
220 |
225 |
217-233 |
207-243 |
214〜266 |
206-274 |
218-262 |
400 |
|
250 |
φ8 |
272 |
245 |
237-253 |
227-263 |
420 |
|||
|
300 |
324 |
450 |
|||||||
